Wall Hung Trough Urinal with Automatic Flushing - 2100mm

There is a choice of left, right (when facing the trough) or centre waste outlet. If the option box is not changed when placing an order, a LEFT waste version will be supplied.



If the cistern is to be concealed behind panels or a wall, the water connection to the urinal can be specified to enter from the rear of the trough. If "rear-entry" is not specified, a top-entry version of the urinal will be supplied for use with a cistern fixed directly above, not behind, the urinal.



Water regulations require that urinals are fitted with a mechanical or

electronic device to restrict flushing. Standard urinal cisterns flush as soon as they are full. The Marnic Water Watch controls the flow of water into the cistern, using a Passive Infra Red sensor to detect when someone has approached a bank of urinals. It then starts an electronic timer to initiate a flush after the number of minutes you have chosen, typically 20 minutes. If nobody approaches the urinals, for example at night or over the weekend, a 'hygiene flush' will be initiated, generally after 12 hours of inactivity. This feature is important to prevent odours on a Monday morning, for example. Click here for a wider choice of flush controllers suitable for urinal troughs, including mains powered models.



More than 95% of urinal trough buyers choose the plastic cistern supplied as standard. However,

a high quality and  robust stainless steel cistern is available for an additional cost. This cistern is manufactured in 1 piece, without joints or crevices from 304 grade stainless steel, with all surfaces polished to a satin finish. It comes complete with a removable lid held in position by security type screws and all standard fittings, including a petcock valve.



Dimensions are : height = 322mm, width = 484mm, projection from wall = 165mm (max)



For additional vandal resistance, a stainless steel downpipe cover can be provided to protect the supply pipe from the cistern to the urinal. This can only be used with a stainless steel cistern (see option above).



To protect the trap and waste pipe, a stainless steel trap cover can be supplied.
