We offer high-quality stainless steel urinal troughs, including popular wall-hung models, available for fast delivery. Choose from four standard sizes, with bespoke sizes and options available upon request. All our urinals come complete with a plastic cistern, connecting pipes, and a waste outlet.
Single Bowl Concealed Trap Stainless Steel Urinal
SBUBI
|
A wall-mounted stainless steel bowl urinal with a compact, anti-vandal design, ideal for concealed pipework or IPS panel installation. Made from 1.2mm thick, bacteriostatic 304 stainless steel, with a satin finish. Up to four urinals can be installed in a range and flushed using a single automatic cistern, with options for a back water inlet with a concealed cistern or a top water inlet with an exposed cistern. For a direct flush setup, select the back inlet, urinal-only option and choose from our direct flush sensors in the related products section below. Also compatible with some in-wall frame systems on the market. Note: Waste pipes must terminate horizontally behind the urinal, NOT suitable for vertical, surface-mounted waste pipes. Supplied with a 1½” P trap, waste fitting, and flexible stainless steel hose connection, with options for cistern and sparge pipes for installations of up to four urinals. Note: Concealed installations should include a service duct behind the urinal(s) to accommodate pipework. Additionally, incorporating access panels into the installation is advisable for easy maintenance and adjustments. Bowl Dimensions: Width= 350mm Projection from wall = 385mm Height = 585mm Weight= 7.5kg |
£365.00
(ex VAT)
Stainless Steel Wall Hung Urinal Trough with Cistern - 4 Lengths Available
GW-WHU1200TI-L
|
New Range of High-Quality Wall-Hung Urinals. The Left-Hand Drain 1800mm model is currently out of stock, with new stock anticipated around 9th January 2025. The Right-Hand Drain 1500mm model has low stock, with additional stock expected around 17th January 2025. Upgrade your high-traffic washroom with this stainless steel wall-hung urinal, perfect for schools, offices, factories, sports facilities, and more. The satin-polished, non-reflective surface offers a modern and clean appearance. Manufactured in the UK from durable 1.2mm grade 304 stainless steel, our wall-hung urinals feature fully boxed two-layered safety ends and front lip, eliminating narrow single sheet edges and potential dirt traps commonly found on lower-quality folded products. This wall hung urinal is supplied as a complete pack, including a white plastic WRAS-approved automatic flushing cistern, stainless steel downpipe, and a sparge pipe situated below an integral valance. The package also includes a 2" domed plastic urinal waste, accommodating the preference for 50mm urinal waste pipes with many installers. An optional reducer to 40mm is also available. Projection from wall = 300mm Height = 465mm Pack Includes: |
£385.00
(ex VAT)
Floor Standing Stainless Steel Urinal
GW-FSTU1200TI-L
|
Standard lengths = 1200mm, 1500mm, 1800mm, 2400mm. These floor-standing urinals have been the popular choice for public toilets and high-traffic gents' washrooms for many years. The low front design makes them more accessible for children, while the side panels provide a degree of privacy for users. They offer a modern and cost-effective alternative to the traditional ceramic floor standing recessed versions sometimes found in older buildings. Unlike their recessed ceramic counterparts, these urinals are not installed into the floor. The waste pipe is above the floor but concealed behind a full-length panel, allowing for ease of installation and maintenance, as the panel can be removed via security screws. When replacing floor recessed ceramic models, installers typically fill in the trench before fitting this style. The urinal trough is manufactured to order in the UK as a one piece unit from 1.2mm thick, grade 304 stainless steel. The surface is polished to a smooth, satin, non-reflective finish. The urinal can be configured for back inlet entry of the downpipe, thus allowing the cistern and downpipe to be hidden behind panels or a stud wall.
For custom lengths and configurations, including "L" shapes, multiple units with joining strips, and bespoke sizes, please email your requirements to sales@gentworks.co.uk, along with the approximate delivery location. We will provide you with a quote and the current lead time. Please note that lead times for bespoke items will be longer. Projection from wall = 265mm Height = 1033mm Pack Includes: Delivery Restrictions for 2400mm Urinals: |
